Giant Revolt Advanced Frameset

Giant Revolt Advanced Frameset
  • Color: Chameleon Saturn
  • Color: Chameleon Saturn
  • Color: Carbon
$2,100.00
Color:
Size: Select size
Please select options Unavailable

Details

Designed with purpose-built geometry for gravel riding, plus engineered compliance in a lightweight composite frame, the Revolt Advanced is the perfect way to push new limits of speed on variable terrain. The frame is integrated for disc brakes and has clearance for high-volume tires up to 45mm so you can float through the rough stuff. Details including the X-Defender downtube protector and smart mount system for racks and accessories give you a head start on any gravel riding mission.

ADVANCED COMPOSITE GRADE FRAME
High-performance grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of the frameset is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.

ADVANCED GRADE COMPOSITE FORK
Composite fork with an OverDrive tapered steer tube absorbs road shock and vibrations and allows for added tire clearance up to 45c.

COMPACT ROAD DESIGN
A downward-sloping top tube (from the head tube to the seat tube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.

DISC-BRAKE INTEGRATION
Frame is engineered with flat-mount disc-brake integration for superior braking performance in all weather and road conditions.

OVERDRIVE
Giant's original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system's oversized headset bearings (1 1/4" lower and 1 1/8" upper) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

MEGADRIVE
A massive rectangular downtube forms the link between the oversized OverDrive system and the PowerCore bottom bracket. This precisely engineered, rectangular shape yields unprecedented steering and pedaling stiffness while minimizing weight.

POWERCORE
A massively oversized bottom bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design. Asymmetric chainstays provide additional stiffness on the drive-side and stability on the non-drive side.

SMART MOUNTING SYSTEM
Compatible with third-party accessories, this integrated mounting system makes it easy to customize with racks, fenders, and more.

Specs

Frame Advanced-Grade Composite, 12x142mm thru-axle, disc
Fork Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Seatpost Giant D-Fuse SLR, composite

* Subject to change without notice.

Part Numbers

Option UPC MPN
Chameleon Saturn / X-Small 4712878581968 2109011103
Chameleon Saturn / Small 4712878581975 2109011104
Chameleon Saturn / Medium 4712878581982 2109011105
Chameleon Saturn / Medium/Large 4712878581999 2109011106
Chameleon Saturn / Large 4712878582002 2109011107
Chameleon Saturn / X-Large 4712878582019 2109011108
Carbon / X-Small 4712878610248 2109012103
Carbon / Small 4712878610255 2109012104
Carbon / Medium 4712878610262 2109012105
Carbon / Medium/Large 4712878610279 2109012106
Carbon / Large 4712878610286 2109012107
Carbon / X-Large 4712878610293 2109012108
